Volkswagen 01M Transmission. Manual - part 2

EV-7

(N94)

EV-4

(N91)

EV-3

(N90)

EV-5

(N92)

EV-1

(N88)

EV-2

(N89)

EV-6

(N93)

1

2

3

4

5

6

7

8

12

10

1

2

4

3

7

5

6

10

8

12

Transmission Fluid

Temp Sensor

View Looking Into

Transmission

Case Connector

Case Connector

Pin No's.

1 And 3

1 And 4

1 And 5

1 And 6

1 And 7

2 And 8

1 And 10

1 And 12

Component

Resistance @ 20°C (72°F)

55-65 Ohms

55-65 Ohms

55-65 Ohms

55-65 Ohms

55-65 Ohms

190k-200k Ohms

4.5-5.1 Ohms

4.5-5.1 Ohms

Solenoid EV-1 (N88)

Solenoid EV-2 (N89)

Solenoid EV-3 (N90)

Solenoid EV-4 (N91)

Solenoid EV-5 (N92)

Solenoid EV-6 (N93)

Solenoid EV-7 (N94)

TFT Sensor

INTERNAL COMPONENT RESISTANCE CHART

Figure 4



Technical Service Information



INDEX

x

x

x

x

x

x

EV4 (N91) AND EV6 (N93)

SOLENOID CHECK AND OPERATION

EV1 (N88), EV2 (N89), EV3 (N90), EV5 (N92) AND EV7 (N94)

SOLENOID CHECK AND OPERATION

SOLENOID OFF

SOLENOID OFF

SOLENOID ON

SOLENOID ON

FROM SOLENOID

REGULATOR VALVE

FROM SOLENOID

REGULATOR VALVE

FROM SOLENOID

REGULATOR VALVE

FROM SOLENOID

REGULATOR VALVE

.030" ORIFICE IN

CASTING

.030"  OR .040"

ORIFICE IN

CASTING

.030"  OR .040"

ORIFICE IN

CASTING

SHIFT VALVE

SHIFT VALVE

.030" ORIFICE IN

CASTING

SOLENOID DIAMETER

.785"

SOLENOID DIAMETER

.800"

WHEN THE SOLENOID IS "OFF"

ORIFICED SOLENOID REGULATOR

OIL WILL EXHAUST OUT THE END

OF THE SOLENOID

WHEN THE SOLENOID IS "OFF"

ORIFICED SOLENOID REGULATOR

OIL WILL EXHAUST OUT THE SIDE

OF THE SOLENOID

WHEN THE SOLENOID IS "ON"

ORIFICED SOLENOID REGULATOR

OIL WILL BUILD UP UNDER THE

SOLENOID STROKING THE VALVE

THAT THE SOLENOID CONTROLS

WHEN THE SOLENOID IS "ON"

ORIFICED SOLENOID REGULATOR

OIL WILL BUILD UP UNDER THE

SOLENOID STROKING THE VALVE

THAT THE SOLENOID CONTROLS

Figure 5



Technical Service Information



INDEX

3



 1

3



 1

PP

AUDI AND VOLKSWAGEN 01M VALVE BODY

Upper valve body

Spacer Plate

Main Valve Body

Assembly

Lower valve body

Spacer Plate

Channel Plate

Figure 6



Technical Service Information



INDEX

01M 325 105

009160

LDL

2

Germany

3

     1

3

     1

PP

3

     1

3

     1

P P

1

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

AUDI AND VOLKSWAGEN 01M VALVE BODY

EXPLODED VIEW

Figure 7



Technical Service Information



INDEX
