P2095



B Camshaft Position Actuator Control Circuit High, Bank 2

P2096



Post Catalyst Fuel Trim System Too Lean Bank 1

P2097



Post Catalyst Fuel Trim System Too Rich Bank 1

P2098



Post Catalyst Fuel Trim System Too Lean Bank 2

P2099



Post Catalyst Fuel Trim System Too Rich Bank 2

P2100



Throttle Actuator Control Motor Circuit/Open

P2101



Throttle Actuator Control Motor Circuit Range/Performance

P2102



Throttle Actuator Control Motor Circuit Low

P2103



Throttle Actuator Control Motor Circuit High

P2106



Throttle Actuator Control System - Forced Limited Power

P2108



Throttle Actuator Control Module Performance

P2110



Throttle Actuator Control System - Forced Limited RPM

P2122



Throttle/Pedal Position Sensor/Switch "D" Circuit Low

P2123



Throttle/Pedal Position Sensor/Switch "D" Circuit High

P2127



Throttle/Pedal Position Sensor/Switch "E" Circuit Low

P2128



Throttle/Pedal Position Sensor/Switch "E" Circuit High

P2133



Throttle/Pedal Position Sensor/Switch "F" Circuit High

P2138



Throttle/Pedal Position Sensor/Switch "D"/"E" Voltage Correlation



P2146



Fuel Injector Group "A" Supply Voltage Circuit/Open

P2149



Fuel Injector Group "B" Supply Voltage Circuit/Open

P2152



Fuel Injector Group "C" Supply Voltage Circuit/Open

P2177



System Too Lean Off Idle, Bank 1

P2178



System Too Rich Off Idle, Bank 1

P2179



System Too Lean Off Idle, Bank 2

P2180



System Too Rich Off Idle, Bank 2

P2181



Cooling System Performance

P2184



Engine Coolant Temperature Sensor 2 Circuit Low

P2185



Engine Coolant Temperature Sensor 2 Circuit High

P2187



System Too Lean at Idle, Bank 1

P2188



System Too Rich at Idle, Bank 1

P2189



System Too Lean at Idle

P2190



System Too Rich at Idle

P2191



System Too Lean at Higher Load, Bank 1

P2192



System Too Rich at Higher Load, Bank 1

P2193



System Too Lean at Higher Load, Bank 2

P2194



System Too Rich at Higher Load, Bank 2

P2195



O2 Sensor Signal Biased/Stuck Lean, Bank 1 Sensor 1

P2196



O2 Sensor Signal Biased/Stuck Rich, Bank 1 Sensor 1

P2197



O2 Sensor Signal Biased/Stuck Lean

P2198



O2 Sensor Signal Biased/Stuck Rich, Bank 2 Sensor 1

P2199



Intake Air Temperature Sensor 1/ 2 Correlation

P2231



O2 Sensor Signal Circuit Shorted to Heater Circuit, Bank 1 Sensor
1



P2234



O2 Sensor Signal Circuit Shorted to Heater Circuit, Bank 2 Sensor
1



P2237



O2 Sensor Positive Current Control Circuit/Open, Bank 1 Sensor 1



Page 18 of 24

Volkswagen Engine and Transmission Fault Codes

12/3/2008

file://Z:\DOCS to be posted to Erwin\Volkswagen Engine and Transmission Fault Codes.h...

P2238



O2 Sensor Positive Current Control Circuit Low

P2239



O2 Sensor Positive Current Control Circuit High

P2240



O2 Sensor Positive Current Control Circuit/Open, Bank 2 Sensor 1



P2241



O2 Sensor Positive Current Control Circuit Low

P2242



O2 Sensor Positive Current Control Circuit High

P2243



O2 Sensor Reference Voltage Circuit/Open, Bank 1 Sensor 1



P2245



O2 Sensor Reference Voltage Circuit Low

P2246



O2 Sensor Reference Voltage Circuit High

P2247



O2 Sensor Reference Voltage Circuit/Open, Bank 2 Sensor 1



P2249



O2 Sensor Reference Voltage Circuit Low

P2250



O2 Sensor Reference Voltage Circuit High

P2251



O2 Sensor Negative Current Control Circuit/Open, Bank 1 Sensor
1



P2252



O2 Sensor Negative Current Control Circuit Low

P2253



O2 Sensor Negative Current Control Circuit High

P2254



O2 Sensor Negative Current Control Circuit/Open, Bank 2 Sensor
1



P2255



O2 Sensor Negative Current Control Circuit Low

P2256



O2 Sensor Negative Current Control Circuit High

P2257



Secondary Air Injection System Control "A" Circuit Low

P2258



Secondary Air Injection System Control "A" Circuit High

P2263



Turbocharger/Supercharger Boost System Performance

P2270



O2 Sensor Signal Stuck Lean, Bank 1 Sensor 2

P2271



O2 Sensor Signal Stuck Rich, Bank 1 Sensor 2

P2272



O2 Sensor Signal Stuck Lean, Bank 1 Sensor 2

P2273



O2 Sensor Signal Stuck Rich, Bank 1 Sensor 2

P2274



O2 Sensor Signal Stuck Lean, Bank 1 Sensor 3

P2275



O2 Sensor Signal Stuck Rich, Bank 1 Sensor 3

P2279



Intake Air System Leak

P2293



Fuel Pressure Regulator 2 Performance

P2294



Fuel Pressure Regulator 2 Control Circuit

P2295



Fuel Pressure Regulator 2 Control Circuit Low

P2296



Fuel Pressure Regulator 2 Control Circuit High

P2300



Ignition Coil "A" Primary Control Circuit Low

P2301



Ignition Coil "A" Primary Control Circuit High

P2303



Ignition Coil "B" Primary Control Circuit Low

P2304



Ignition Coil "B" Primary Control Circuit High

P2306



Ignition Coil "C" Primary Control Circuit Low

P2307



Ignition Coil "C" Primary Control Circuit High

P2309



Ignition Coil "D" Primary Control Circuit Low

P2310



Ignition Coil "D" Primary Control Circuit High

P2312



Ignition Coil "E" Primary Control Circuit Low

P2313



Ignition Coil "E" Primary Control Circuit High

P2315



Ignition Coil "F" Primary Control Circuit Low

P2316



Ignition Coil "F" Primary Control Circuit High

Page 19 of 24

Volkswagen Engine and Transmission Fault Codes

12/3/2008

file://Z:\DOCS to be posted to Erwin\Volkswagen Engine and Transmission Fault Codes.h...

P2400



Evaporative Emission System Leak Detection Pump Control
Circuit/Open



P2401



Evaporative Emission System Leak Detection Pump Control Circuit
Low



P2402



Evaporative Emission System Leak Detection Pump Control Circuit
High



P2403



Evaporative Emission System Leak Detection Pump Sense
Circuit/Open



P2404



Evaporative Emission System Leak Detection Pump Sense Circuit
Range/Performance



P2413



Exhaust Gas Recirculation System Performance

P2414



O2 Sensor Exhaust Sample Error, Bank 1 Sensor 1

P2415



O2 Sensor Exhaust Sample Error, Bank 2 Sensor 1

P2416



O2 Sensor Signals Swapped, Bank 1 Sensor 2/Bank 1 Sensor 3



P2422



Evaporative Emission System Vent Valve Stuck Closed

P2425



Exhaust Gas Recirculation Cooling Valve Control Circuit/Open



P2426



Exhaust Gas Recirculation Cooling Valve Control Circuit Low



P2427



Exhaust Gas Recirculation Cooling Valve Control Circuit High



P2539



Low Pressure Fuel System Sensor Circuit

P2540



Low Pressure Fuel System Sensor Circuit Range/Performance



P2541



Low Pressure Fuel System Sensor Circuit Low

P2564



Turbocharger Boost Control Position Sensor "A" Circuit Low



P2565



Turbocharger Boost Control Position Sensor "A" Circuit High



P2600



Coolant Pump Control Circuit/Open

P2602



Coolant Pump Control Circuit Low

P2603



Coolant Pump Control Circuit High

P2626



O2 Sensor Pumping Current Trim Circuit/Open, Bank 1 Sensor 1



P2629



O2 Sensor Pumping Current Trim Circuit/Open, Bank 1 Sensor 1



P2632



Fuel Pump "B" Control Circuit /Open

P2634



Fuel Pump "B" Control Circuit High

P2637



Torque Management Feedback Signal "A"

P2714



Pressure Control Solenoid "D" Performance/Stuck Off

P2715



Pressure Control Solenoid "D" Stuck On

P2716



Pressure Control Solenoid "D" Electrical

P2717



Pressure Control Solenoid "D" Intermittent

P2723



Pressure Control Solenoid "E" Performance/Stuck Off

P2724



Pressure Control Solenoid "E" Stuck On

P2725



Pressure Control Solenoid "E" Electrical

P2726



Pressure Control Solenoid "E" Intermittent

P2732



Pressure Control Solenoid "F" Performance/Stuck Off

P2733



Pressure Control Solenoid "F" Stuck On

P2734



Pressure Control Solenoid "F" Electrical

P2735



Pressure Control Solenoid "F" Intermittent

P3000



Glow Plug Indictor Light -K29- Malfunction Message From
Instrument Cluster



P3011



Fuel Pump (FP) 2 Relay -J49- Short Circuit to B+

Page 20 of 24

Volkswagen Engine and Transmission Fault Codes

12/3/2008

file://Z:\DOCS to be posted to Erwin\Volkswagen Engine and Transmission Fault Codes.h...

P3012



Fuel Pump (FP) 2 Relay -J49- Open Circuit/Short Circuit to Ground
(GND)



P3025



Angle Sensor 1 (on Throttle Drive 2 Power Accelerator Actuation) -
G297- Unplausible Signal



P3026



Angle Sensor 1 (on Throttle Drive 2 Power Accelerator Actuation) -
G297- Signal Too Small



P3027



Angle Sensor 1 (on Throttle Drive 2 Power Accelerator Actuation) -
G297- Signal Too Large



P3028



Angle Sensor 2 (on Throttle Drive 2 Power Accelerator Actuation) -
G298- Unplausible Signal



P3029



Angle Sensor 2 (on Throttle Drive 2 Power Accelerator Actuation) -
G298- Signal Too Small



P3030



Angle Sensor 2 (on Throttle Drive 2 Power Accelerator Actuation) -
G298- Signal Too Large



P3031



Throttle Drive 2 (Power Accelerator Actuation) -G296- Electrical
Malfunction in Circuit



P3032



Throttle Valve Control Module 2 -J544-
Malfunction in Basic Setting



P3033



Intake Air Temperature (IAT) Sensor 2 -G299- Signal Too Small



P3034



Intake Air Temperature (IAT) Sensor 2 -G299- Signal Too Large



P3035



Throttle Valve Control Module 2 -J544- Mechanical Malfunction



P3038



Throttle Valve Control Module 2 -J544- Lower Impact Is Not Being
Reached



P3047



Activation Starter Relay 2 Short Circuit to B+

P3048



Activation Starter Relay 2 Short Circuit to Ground (GND)

P3049



Activation Starter Relay 2 Open Circuit

P3057



Exhaust Pressure Sensor 2 High

P3058



Exhaust Gas Recirc.Flow 2 Insufficient Detected

P3059



Exhaust Gas Recirc.Flow Excessive Detected

P3060



Cooling Bypass Valve, Exhaust Gas Recirculation Flow
Electrical



P3061



Cooling Bypass Valve 2, Exhaust Gas Recirculation Flow
Electrical



P3062



Turbo/Super Charger Overboost Condition

P3063



Turbo/Super Charger Underboost

P3081



Engine Temperature Too Low

P3130



Exhaust Gas Recirculation (EGR) System Control Limit Exceeded



P3131



Exhaust Gas Recirculation (EGR) System Lowest Control Limit
Exceeded



P3144



Exhaust-Bank 3, Sensor 1, Oxygen Sensor Signal Implausibly
Lean



P3145



Exhaust-Bank 3, Sensor 1, Oxygen Sensor Signal Implausibly Rich



P3146



Exhaust-Bank 4, Sensor 1, Oxygen Sensor Signal Implausibly
Lean



P3147



Exhaust-Bank 4, Sensor 1, Oxygen Sensor Signal Implausibly Rich



P3148



Exhaust-Bank 3, Oxygen Sensor Before Cat, Heater Circuit
Regulation at Upper Impact
