P0783



3-4 Shift

P0784



4-5 Shift

P0785



Shift Timing Solenoid "A"

P0791



Intermediate Shaft Speed Sensor "A" Circuit

P0796



Pressure Control Solenoid "C" Performance/Stuck Off

P0797



Pressure Control Solenoid "C" Stuck On

P0798



Pressure Control Solenoid "C" Electrical

P0799



Pressure Control Solenoid "C" Intermittent

P0811



Excessive Clutch "A" Slippage

P0820



Gear Lever X-Y Position Sensor Circuit

P0821



Gear Lever X Position Circuit

P0822



Gear Lever Y Position Circuit

P0829



5-6 Shift



P0838



Four Wheel Drive (4WD) Switch Circuit Low

P0840



Transmission Fluid Pressure Sensor/Switch "A" Circuit

P0841



Transmission Fluid Pressure Sensor/Switch "A" Circuit
Range/Performance



P0842



Transmission Fluid Pressure Sensor/Switch "A" Circuit Low

P0845



Transmission Fluid Pressure Sensor/Switch "B" Circuit

P0846



Transmission Fluid Pressure Sensor/Switch "B" Circuit
Range/Performance



P0863



TCM Communication Circuit

P0864



TCM Communication Circuit Range/Performance

P0865



TCM Communication Circuit Low

P0884



TCM Power Input Signal Intermittent

P0886



TCM Power Relay Control Circuit Low

P0887



TCM Power Relay Control Circuit High

P0889



TCM Power Relay Sense Circuit Range/Performance

P0890



TCM Power Relay Sense Circuit Low

P0891



TCM Power Relay Sense Circuit High

P0892



TCM Power Relay Sense Circuit Intermittent

P0914



Gear Shift Position Circuit

P0915



Gear Shift Position Circuit Range/Performance

P0918



Gear Shift Position Circuit Intermittent

P0919



Gear Shift Position Control Error

P0929



Gear Shift Lock Solenoid Control Circuit Range/Performance



P1009



Air Mass Meter 1/2 Implausible Signal from Load Detection

P1026



Activation Intake Manifold Flap for Air Stream Regulation Short
Circuit to B+



P1027



Activation Intake Manifold Flap for Air Stream Regulation Short
Circuit to Ground (GND)



P1028



Activation Intake Manifold Flap for Air Stream Regulation Open
Circuit



P1073



Mass Air Flow (MAF) Sensor 2 -G246- Signal Too Small

P1074



Mass Air Flow (MAF) Sensor 2 -G246- Signal Too Large

P1081



Exhaust-Bank3, Mixture Adaptation Range 1 Lower Lean Limit Not

Page 10 of 24

Volkswagen Engine and Transmission Fault Codes

12/3/2008

file://Z:\DOCS to be posted to Erwin\Volkswagen Engine and Transmission Fault Codes.h...

Reached

P1082



Exhaust-Bank3, Mixture Adaptation Range 2 Lower Lean Limit Not
Reached



P1083



Exhaust-Bank3, Mixture Adaptation Range 1 Rich Limit Exceeded



P1084



Exhaust-Bank3, Mixture Adaptation Range 2 Rich Limit Exceeded



P1085



Exhaust-Bank4, Mixture Adaptation Range 1 Lower Lean Limit Not
Reached



P1086



Exhaust-Bank4, Mixture Adaptation Range 2 Lower Lean Limit Not
Reached



P1087



Exhaust-Bank4, Mixture Adaptation Range 1 Rich Limit Exceeded



P1088



Exhaust-Bank4, Mixture Adaptation Range 2 Rich Limit Exceeded



P1102



HO2S Heater Control Circuit (Bank 1 Sensor 1) High

P1103



Bank1-Probe1, Heating Circuit Output Too Low

P1105



HO2S Heater Control Circuit (Bank 1 Sensor 2) High

P1107



HO2S Heater Control Circuit (Bank 2 Sensor 1) High

P1110



HO2S Heater Control Circuit (Bank 2 Sensor 2) High

P1113



Bank1, Sensor 1 Internal Resistance Too Large

P1114



Bank 1, sensor 2 Internal resistance too large

P1115



HO2S Heater Control Circuit (Bank 1 Sensor 1) Low

P1116



HO2S Heater Control Circuit (Bank 1 Sensor 1)

P1117



HO2S Heater Control Circuit (Bank 1 Sensor 2) Low

P1118



HO2S Heater Control Circuit (Bank 1 Sensor 2)

P1127



Bank1, Mixture Adaption (mult.) System Too Rich

P1128



Bank1, Mixture Adaption (mult.) System Too Lean

P1129



Bank2,  Mixture Adaption (mult.) System Too Rich

P1130



Bank2,  Mixture Adaption (mult.) System Too Lean

P1136



Bank1, Mixture Adaption (add.) System Too Lean

P1137



Bank1, Mixture Adaption (add.) System Too Rich

P1138



Bank2, mixture adaption (add.) system too lean

P1139



Bank2, Mixture Adaption (add.) System Too Rich

P1141



Load Detection Implausible Value

P1142



Load Detection Value Below Lower Limit

P1143



Load Detection Value Above Upper Limit

P1144



Mass Air Flow (MAF) Sensor -G70- Open Circuit/Short Circuit to
Ground (GND)



P1145



Mass Air Flow (MAF) Sensor -G70- Short Circuit to B+

P1146



Air Mass Meter -G70 Supply Voltage

P1151



Long Term Fuel Trim Additive Air., Area 1 System Too Lean



P1152



Long Term Fuel Trim Additive Air., Area 2 System Too Lean



P1155



Manifold Absolute Pressure (MAP) Sensor -G71- Short Circuit to
B+



P1156



Manifold Absolute Pressure (MAP) Sensor -G71- Open
Circuit/Short to Ground (GND)



P1157



Manifold Absolute Pressure/Barometric Pressure Circuit

P1160



Intake Air Temperature (IAT) Sensor -G72- Short Circuit to Ground
(GND)



Page 11 of 24

Volkswagen Engine and Transmission Fault Codes

12/3/2008

file://Z:\DOCS to be posted to Erwin\Volkswagen Engine and Transmission Fault Codes.h...

P1161



Intake Air Temperature (IAT) Sensor -G72- Open Circuit/Short
Circuit to B+



P1162



Fuel Temperature Sensor A Circuit Low

P1163



Fuel Temperature Sensor A Circuit High

P1164



Fuel Temperature Sensor -G81- Unplausible Signal

P1165



Long Term Fuel Trim Additive Air., Area 1 System Too Rich

P1166



Long Term Fuel Trim Additive Air., Area 2 System Too Rich

P1167



Mass Air Flow (MAF) Sensor 2 -G246- Unplausible Signal

P1171



Angle Sender 2 for Throttle Valve Drive -G188 Implausible Signal



P1172



Angle Sender 2 for Throttle Valve Drive -G188 Signal Too Low



P1173



Angle sender 2 for throttle valve drive -G188 Signal Too High



P1174



Fuel Trim, Bank 1 Injection Timing Deviation

P1175



Pre-Injection Switched Off

P1176



Bank1, Lambda Correction Downstream of Catalyst Control Limit
Reached



P1177



Bank2, Lambda Correction Downstream of Catalyst Control Limit
Reached



P1196



O2 Sensor Heater Circuit, Bank1 Sensor1 Electrical Fault

P1197



O2 Sensor Heater Circuit, Bank2 Sensor1 Electrical Fault

P1198



O2 Sensor Heater Circuit, Bank1 Sensor2 Eletrical Fault

P1199



HO2S Heater Control Circuit, Bank2 Sensor2

P1213



Cylinder 1 Injector Circuit High

P1214



Cylinder 2 Injector Circuit High

P1215



Cylinder 3 Injector Circuit High

P1216



Cylinder 4 Injector Circuit High

P1217



Cylinder 5 Fuel Injector -N83- Short circuit to B+

P1218



Cylinder 6 Fuel Injector -N84- Short circuit to B+

P1225



Cylinder 1 Injector Circuit Low

P1226



Cylinder 2 Injector Circuit Low

P1227



Cylinder 3 Injector Circuit Low

P1228



Cylinder 4 Injector Circuit Low

P1229



Cylinder 5 Fuel Injector -N83- Short Circuit to Ground (GND)



P1230



Cylinder 6 Fuel Injector -N84- Short Circuit to Ground (GND)



P1237



Cylinder 1 Injector -N30 Open Circuit

P1238



Cylinder 2 Injector -N31 Open Circuit

P1239



Cylinder 3 Injector -N32 Open Circuit

P1240



Cylinder 4 Injector -N33 Open Circuit

P1241



Cylinder 5 Injector -N83 Open Circuit

P1242



Cylinder 6 Injector -N84 Open Circuit

P1245



Needle Lift Sensor -G80- Short Circuit to Ground (GND)

P1246



Needle Lift Sender -G80 Implausible Signal

P1247



Needle Lift Sensor -G80- Open Circuit/Short Circuit to B+

P1248



Injection Pump Fuel Metering Control (A) Range/Performance



P1250



Fuel Level Too Low



P1251



Cold Start Injector -N108- Short Circuit to B+

P1252



Cold Start Injector -N108- Open Circuit/Short Circuit to Ground

Page 12 of 24

Volkswagen Engine and Transmission Fault Codes

12/3/2008

file://Z:\DOCS to be posted to Erwin\Volkswagen Engine and Transmission Fault Codes.h...

GND)



P1255



Engine Coolant Temperature (ECT) Sensor -G62- Short Circuit to
Ground



P1256



Engine Coolant Temperature (ECT) Sensor -G62- Open
Circuit/Short Circuit to B+



P1280



Air Control Valve for Injectors -N212 Air Flow Too Low

P1296



Malfunction in Cooling System

P1300



Misfire Detected Low Fuel

P1321



Knock Sensor 3-G198 Signal Too Low

P1322



Knock Sensor 3-G198 Signal Too High

P1323



Knock Sensor 4-G199 Signal Too Low

P1324



Knock Sensor 4-G199 Signal Too High

P1335



Engine Torque Monitoring 2 Value Above Upper Control Limit



P1336



EngineTorque Monitoring Value Above Upper Control Limit

P1337



Bank1, Camshaft Position (CMP) =>Sensor -G40- Short Circuit to
Ground (GND)



P1338



Bank 1, Camshaft Position (CMP) Sensor -G40- = > Open
Circuit/Short Circuit to Ground (GND)



P1340



Camshaft Position Sensor-G40, Engine Speed Sensor-G28
Incorrect Allocation



P1341



Ignition Coil Power Output Stage 1 Short Circuit to Ground (GND)



P1343



Ignition Coil Power Output Stage 2 Short circuit to Ground (GND)



P1345



Ignition Coil Power Output Stage 3 Short Circuit to Ground (GND)



P1354



Modulating Piston Movement Sender -G149 Electrical Fault in
Circuit



P1355



Ignition Activation Cylinder 1 Open Circuit

P1356



Ignition Activation Cylinder 1 Short Circuit to B+

P1357



Ignition Activation Cylinder 1 Short Circuit to Ground (GND)

P1358



Ignition Activation Cylinder 2 Open Circuit

P1359



Ignition Activation Cylinder 2 Short Circuit to B+

P1360



Ignition Activation Cylinder 2 Short Circuit to Ground (GND)

P1361



Ignition Activation Cylinder 3 Open Circuit

P1362



Ignition Activation Cylinder 3 Short Circuit to B+

P1363



Ignition Activation Cylinder 3 Short Circuit to Ground (GND)

P1364



Ignition Activation Cylinder 4 Open Circuit

P1365



Ignition Activation Cylinder 4 Short Circuit to B+

P1366



Ignition Activation Cylinder 4 Short Circuit to Ground (GND)

P1387



Internal Control Module Memory Check Sum Error

P1388



Internal Control Module Memory Check Sum Error

P1391



Bank2, Camshaft Position (CMP) =>Sensor 2 -G163- Short Circuit
to Ground (GND)



P1392



Bank2, Camshaft Position (CMP) = >Sensor 2 -G163- Open
Circuit/Short Circuit to B+



P1393



Ignition Output 1 Electrical Fault in Circuit

P1394



Ignition Output 2 Electrical Fault in Circuit

P1395



Ignition Output 3 Electrical Fault in Circuit
