P0057



HO2S Heater Control Circuit Low, Bank 2 Sensor 2

P0058



HO2S Heater Control Circuit High, Bank 2 Sensor 2

P0068



MAP/MAF - Throttle Position Correlation

P0087



Fuel Rail/System Pressure - Too Low

P0088



Fuel Rail/System Pressure - Too High

P0089



Fuel Pressure Regulator 1 Performance

P0097



Intake Air Temperature Sensor 2 Circuit Low

P0098



Intake Air Temperature Sensor 2 Circuit High

P0100



Mass or Volume Air Flow "A" Circuit

P0101



Mass or Volume Air Flow "A" Circuit Range/Performance

P0102



Mass or Volume Air Flow "A" Circuit Low

P0103



Mass or Volume Air Flow "A" Circuit High

P0105



Manifold Absolute Pressure/Barometric Pressure Circuit

P0106



Manifold Absolute Pressure/Barometric Pressure Circuit
Range/Performance



P0107



Manifold Absolute Pressure/Barometric Pressure Circuit Low



P0108



Manifold Absolute Pressure/Barometric Pressure Circuit High



P0112



Intake Air Temperature Sensor 1 Circuit Low

P0113



Intake Air Temperature Sensor 1 Circuit High

P0116



Engine Coolant Temperature Sensor 1 Circuit Range/Performance



P0117



Engine Coolant Temperature Sensor 1 Circuit Low

P0118



Engine Coolant Temperature Sensor 1 Circuit High

P0120



Throttle/Pedal Position Sensor/Switch "A" Circuit

P0121



Throttle/Pedal Position Sensor/Switch "A" Circuit
Range/Performance



P0122



Throttle/Pedal Position Sensor/Switch "A" Circuit Low

P0123



Throttle/Pedal Position Sensor/Switch "A" Circuit High

P0125



Insufficient Coolant Temperature for Closed Loop Fuel Control



P0128



Coolant Thermostat (Coolant Temperature Below Thermostat
Regulating Temperature)



P0130



O2 Sensor Circuit, Bank 1 Sensor 1

P0131



O2 Sensor Circuit Low Voltage, Bank 1 Sensor 1

P0132



O2 Sensor Circuit High Voltage, Bank 1 Sensor 1

P0133



O2 Sensor Circuit Slow Response, Bank 1 Sensor 1

P0134



O2 Sensor Circuit No Activity Detected, Bank 1 Sensor 1

P0135



O2 Sensor Heater Circuit, Bank 1 Sensor 1

P0136



O2 Sensor Circuit, Bank 1 Sensor 2

P0137



O2 Sensor Circuit Low Voltage, Bank 1 Sensor 2

P0138



O2 Sensor Circuit High Voltage, Bank 1 Sensor 2

P0139



O2 Sensor Circuit Slow Response, Bank 1 Sensor 2

P0140



O2 Sensor Circuit No Activity Detected, Bank 1 Sensor 2

P0141



O2 Sensor Heater Circuit, Bank 1 Sensor 2

P0142



O2 Sensor Circuit, Bank 1 Sensor 3

P0143



O2 Sensor Circuit Low Voltage, Bank 1 Sensor 3

P0144



O2 Sensor Circuit High Voltage, Bank 1 Sensor 3

P0145



O2 Sensor Circuit Slow Response, Bank 1 Sensor 3

Page 2 of 24

Volkswagen Engine and Transmission Fault Codes

12/3/2008

file://Z:\DOCS to be posted to Erwin\Volkswagen Engine and Transmission Fault Codes.h...

P0146



O2 Sensor Circuit No Activity Detected, Bank 1 Sensor 3

P0147



O2 Sensor Heater Circuit, Bank 1 Sensor 3

P0150



O2 Sensor Circuit, Bank 2 Sensor 1

P0151



O2 Sensor Circuit Low Voltage, Bank 2 Sensor 1

P0152



O2 Sensor Circuit High Voltage, Bank 2 Sensor 1

P0153



O2 Sensor Circuit Slow Response, Bank 2 Sensor 1

P0154



O2 Sensor Circuit No Activity Detected, Bank 2 Sensor 1

P0155



O2 Sensor Heater Circuit, Bank 2 Sensor 1

P0156



O2 Sensor Circuit, Bank 2 Sensor 2

P0157



O2 Sensor Circuit Low Voltage, Bank 2 Sensor 2

P0158



O2 Sensor Circuit High Voltage, Bank 2 Sensor 2

P0159



O2 Sensor Circuit Slow Response, Bank 2 Sensor 2

P0160



O2 Sensor Circuit No Activity Detected, Bank 2 Sensor 2

P0161



O2 Sensor Heater Circuit, Bank 2 Sensor 2

P0169



Incorrect Fuel Composition

P0171



System Too Lean, Bank 1

P0172



System Too Rich, Bank 1

P0174



System Too Lean, Bank 2

P0175



System Too Rich, Bank 2

P0181



Fuel Temperature Sensor "A" Circuit Range/Performance

P0182



Fuel Temperature Sensor "A" Circuit Low

P0183



Fuel Temperature Sensor "A" Circuit High

P0188



Fuel Temperature Sensor "B" Circuit High

P0190



Fuel Rail Pressure Sensor "A" Circuit

P0192



Fuel Rail Pressure Sensor "A" Circuit Low

P0200



Injector Circuit/Open



P0201



Injector Circuit/Open - Cylinder 1

P0202



Injector Circuit/Open - Cylinder 2

P0203



Injector Circuit/Open - Cylinder 3

P0204



Injector Circuit/Open - Cylinder 4

P0205



Injector Circuit/Open - Cylinder 5

P0206



Injector Circuit/Open - Cylinder 6

P0207



Injector Circuit/Open - Cylinder 7

P0208



Injector Circuit/Open - Cylinder 8

P0209



Injector Circuit/Open - Cylinder 9

P0210



Injector Circuit/Open - Cylinder 10

P0211



Injector Circuit/Open - Cylinder 11

P0212



Injector Circuit/Open - Cylinder 12

P0216



Injector/Injection Timing Control Circuit

P0219



Engine Overspeed Condition

P0221



Throttle/Pedal Position Sensor/Switch "B" Circuit
Range/Performance



P0222



Throttle/Pedal Position Sensor/Switch "B" Circuit Low

P0223



Throttle/Pedal Position Sensor/Switch "B" Circuit High

P0225



Throttle/Pedal Position Sensor/Switch "C" Circuit

Page 3 of 24

Volkswagen Engine and Transmission Fault Codes

12/3/2008

file://Z:\DOCS to be posted to Erwin\Volkswagen Engine and Transmission Fault Codes.h...

P0226



Throttle/Pedal Position Sensor/Switch "C" Circuit
Range/Performance



P0227



Throttle/Pedal Position Sensor/Switch "C" Circuit Low

P0228



Throttle/Pedal Position Sensor/Switch "C" Circuit High

P0230



System Too Rich at Idle

P0234



Turbocharger/Supercharger Overboost Condition

P0236



Turbocharger/Supercharger Boost Sensor "A" Circuit
Range/Performance



P0237



Turbocharger/Supercharger Boost Sensor "A" Circuit Low

P0238



Turbocharger/Supercharger Boost Sensor "A" Circuit High

P0240



Turbocharger/Supercharger Boost Sensor "B" Circuit
Range/Performance



P0241



Turbocharger/Supercharger Boost Sensor "B" Circuit Low

P0242



Turbocharger/Supercharger Boost Sensor "B" Circuit High

P0243



Turbocharger/Supercharger Wastegate Solenoid "A"

P0245



Turbocharger/Supercharger Wastegate Solenoid "A" Low

P0246



Turbocharger/Supercharger Wastegate Solenoid "A" High

P0247



Turbocharger/Supercharger Wastegate Solenoid "B"

P0249



Turbocharger/Supercharger Wastegate Solenoid "B" Low

P0250



Turbocharger/Supercharger Wastegate Solenoid "B" High

P0251



Injection Pump Fuel Metering Control "A" (Cam/Rotor/Injector)



P0252



Injection Pump Fuel Metering Control "A" Range/Performance
(Cam/Rotor/Injector)



P0261



Cylinder 1 Injector Circuit Low

P0262



Cylinder 1 Injector Circuit High

P0263



Cylinder 1 Contribution/Balance

P0264



Cylinder 2 Injector Circuit Low

P0265



Cylinder 2 Injector Circuit High

P0266



Cylinder 2 Contribution/Balance

P0267



Cylinder 3 Injector Circuit Low

P0268



Cylinder 3 Injector Circuit High

P0269



Cylinder 3 Contribution/Balance

P0270



Cylinder 4 Injector Circuit Low

P0271



Cylinder 4 Injector Circuit High

P0272



Cylinder 4 Contribution/Balance

P0273



Cylinder 5 Injector Circuit Low

P0274



Cylinder 5 Injector Circuit High

P0275



Cylinder 5 Contribution/Balance

P0276



Cylinder 6 Injector Circuit Low

P0277



Cylinder 6 Injector Circuit High

P0278



Cylinder 6 Contribution/Balance

P0279



Cylinder 7 Injector Circuit Low

P0280



Cylinder 7 Injector Circuit High

P0281



Cylinder 7 Contribution/Balance

P0282



Cylinder 8 Injector Circuit Low

P0283



Cylinder 8 Injector Circuit High

Page 4 of 24

Volkswagen Engine and Transmission Fault Codes

12/3/2008

file://Z:\DOCS to be posted to Erwin\Volkswagen Engine and Transmission Fault Codes.h...

P0284



Cylinder 8 Contribution/Balance

P0285



Cylinder 9 Injector Circuit Low

P0286



Cylinder 9 Injector Circuit High

P0287



Cylinder 9 Contribution/Balance

P0288



Cylinder 10 Injector Circuit Low

P0289



Cylinder 10 Injector Circuit High

P0290



Cylinder 10 Contribution/Balance

P0291



Cylinder 11 Injector Circuit Low

P0292



Cylinder 11 Injector Circuit High

P0294



Cylinder 12 Injector Circuit Low

P0295



Cylinder 12 Injector Circuit High

P0299



Turbocharger/Supercharger Underboost Condition

P0300



Random/Multiple Cylinder Misfire Detected

P0301



Cylinder 1 Misfire Detected

P0302



Cylinder 2 Misfire Detected

P0303



Cylinder 3 Misfire Detected

P0304



Cylinder 4 Misfire Detected

P0305



Cylinder 5 Misfire Detected

P0306



Cylinder 6 Misfire Detected

P0307



Cylinder 7 Misfire Detected

P0308



Cylinder 8 Misfire Detected

P0309



Cylinder 9 Misfire Detected

P0310



Cylinder 10 Misfire Detected

P0311



Cylinder 11 Misfire Detected

P0312



Cylinder 12 Misfire Detected

P0318



Rough Road Sensor "A" Signal Circuit

P0321



Ignition/Distributor Engine Speed Input Circuit Range/Performance



P0322



Ignition/Distributor Engine Speed Input Circuit No Signal

P0324



Knock Control System Error

P0327



Knock Sensor 1 Circuit Low Bank 1 or Single Sensor

P0328



Knock Sensor 1 Circuit High  Bank 1 or Single Sensor

P0332



Knock Sensor 2 Circuit Low Bank 2

P0333



Knock Sensor 2 Circuit High Bank 2

P0340



Camshaft Position Sensor "A" Circuit, Bank 1 or Single Sensor



P0341



Camshaft Position Sensor "A" Circuit Range/Performance, Bank 1
or Single Sensor



P0342



Camshaft Position Sensor "A" Circuit Low, Bank 1 or Single
Sensor



P0343



Camshaft Position Sensor "A" Circuit High, Bank 1 or Single
Sensor



P0345



Camshaft Position Sensor "A" Circuit, Bank 2

P0346



Camshaft Position Sensor "A" Circuit Range/Performance, Bank 2



P0347



Camshaft Position Sensor "A" Circuit Low, Bank 2

P0348



Camshaft Position Sensor "A" Circuit High, Bank 2

P0351



Ignition Coil "A" Primary/Secondary Circuit

P0352



Ignition Coil "B" Primary/Secondary Circuit
