Volkswagen 01M Transmission. Manual - part 125

P0353



Ignition Coil "C" Primary/Secondary Circuit

P0354



Ignition Coil "D" Primary/Secondary Circuit

P0355



Ignition Coil "E" Primary/Secondary Circuit

P0356



Ignition Coil "F" Primary/Secondary Circuit

P0357



Ignition Coil "G" Primary/Secondary Circuit

P0358



Ignition Coil "H" Primary/Secondary Circuit

P0359



Ignition Coil "I" Primary/Secondary Circuit

P0360



Ignition Coil "J" Primary/Secondary Circuit

P0361



Ignition Coil "K" Primary/Secondary Circuit

P0362



Ignition Coil "L" Primary/Secondary Circuit

P0365



Camshaft Position Sensor "B" Circuit, Bank 1

P0366



Camshaft Position Sensor "B" Circuit, Bank 1 Range/Performance



P0367



Camshaft Position Sensor "B" Circuit Low, Bank 1

P0368



Camshaft Position Sensor "B" Circuit High, Bank 1

P0380



Glow Plug/Heater Circuit "A"

P0381



Glow Plug/Heater Indicator Circuit

P0391



Camshaft Position Sensor "B" Circuit Range/Performance, Bank 2



P0392



Camshaft Position Sensor "B" Circuit Low, Bank 2

P0393



Camshaft Position Sensor "B" Circuit High, Bank 2

P0400



Exhaust Gas Recirculation Flow

P0401



Exhaust Gas Recirculation Flow Insufficient Detected

P0402



Exhaust Gas Recirculation Flow Excessive Detected

P0403



Exhaust Gas Recirculation Control Circuit

P0404



Exhaust Gas Recirculation Control Circuit Range/Performance



P0411



Secondary Air Injection System Incorrect Flow Detected

P0413



Secondary Air Injection System Switching Valve "A" Circuit Open



P0414



Secondary Air Injection System Switching Valve "A" Circuit
Shorted



P0416



Secondary Air Injection System Switching Valve "B" Circuit Open



P0417



Secondary Air Injection System Switching Valve "B" Circuit
Shorted



P0418



Secondary Air Injection System Control "A" Circuit

P0420



Catalyst System Efficiency Below Threshold, Bank 1

P0421



Warm Up Catalyst Efficiency Below Threshold, Bank 1

P0422



Main Catalyst Efficiency Below Threshold, Bank 1

P0423



Heated Catalyst Efficiency Below Threshold, Bank 1

P0424



Heated Catalyst Temperature Below Threshold, Bank 1

P0425



Catalyst Temperature Sensor Circuit, Bank 1 Sensor 1

P0426



Catalyst Temperature Sensor Circuit Range/Performance, Bank 1
Sensor 1



P0427



Catalyst Temperature Sensor Circuit Low, Bank 1 Sensor 1

P0428



Catalyst Temperature Sensor Circuit High, Bank 1 Sensor 1



P0429



Catalyst Heater Control Circuit, Bank 1

P0430



Catalyst System Efficiency Below Threshold, Bank 2

P0431



Warm Up Catalyst Efficiency Below Threshold, Bank 2

P0432



Main Catalyst Efficiency Below Threshold, Bank 2

Page 6 of 24

Volkswagen Engine and Transmission Fault Codes

12/3/2008

file://Z:\DOCS to be posted to Erwin\Volkswagen Engine and Transmission Fault Codes.h...

P0441



Evaporative Emission System Incorrect Purge Flow

P0442



Evaporative Emission System Leak Detected (small leak)

P0444



Evaporative Emission System Purge Control Valve Circuit Open



P0445



Evaporative Emission System Leak Detected (large leak)

P0449



Evaporative Emission System Vent Valve/Solenoid Circuit

P0455



Evaporative Emission System Leak Detected (large leak)

P0456



Evaporative Emission System Leak Detected (very small leak)



P0458



Evaporative Emission System Purge Control Valve Circuit Low



P0459



Evaporative Emission System Purge Control Valve Circuit High



P0480



Fan 1 Control Circuit



P0481



Fan 2 Control Circuit



P0489



Exhaust Gas Recirculation Control Circuit Low

P0490



Exhaust Gas Recirculation Control Circuit High

P0491



Secondary Air Injection System Insufficient Flow, Bank 1

P0492



Secondary Air Injection System Insufficient Flow, Bank 2

P0498



Evaporative Emission System Vent Valve Control Circuit Low



P0499



Evaporative Emission System Vent Valve Control Circuit High



P0501



Vehicle Speed Sensor "A" Range/Performance

P0505



Idle Air Control System

P0506



Idle Air Control System RPM Lower Than Expected

P0507



Idle Air Control System RPM Higher Than Expected

P0510



Closed Throttle Position Switch

P0544



Exhaust Gas Temperature Sensor Circuit, Bank 1 Sensor 1

P0545



Exhaust Gas Temperature Sensor Circuit Low, Bank 1 Sensor 1



P0546



Exhaust Gas Temperature Sensor Circuit High, Bank 1 Sensor 1



P0562



System Voltage Low



P0563



System Voltage High



P0564



Cruise Control Multi-Function Input "A" Circuit

P0597



Thermostat Heater Control Circuit/Open

P0598



Thermostat Heater Control Circuit Low

P0599



Thermostat Heater Control Circuit High

P0600



Serial Communication Link

P0601



Internal Control Module Memory Check Sum Error

P0602



Control Module Programming Error

P0603



Internal Control Module Keep Alive Memory (KAM) Error

P0604



Internal Control Module Random Access Memory (RAM) Error



P0605



Internal Control Module Read Only Memory (ROM) Error

P0606



Control Module Processor

P0607



Control Module Performance

P0608



Control Module VSS Output "A"

P0609



Control Module VSS Output "B"

P0613



TCM Processor



P0614



ECM / TCM Incompatible

P0627



Fuel Pump "A" Control Circuit/Open

P0629



Fuel Pump "A" Control Circuit High

Page 7 of 24

Volkswagen Engine and Transmission Fault Codes

12/3/2008

file://Z:\DOCS to be posted to Erwin\Volkswagen Engine and Transmission Fault Codes.h...

P0638



Throttle Actuator Control Range/Performance, Bank 1

P0639



Throttle Actuator Control Range/Performance, Bank 2

P0641



Sensor Reference Voltage "A" Circuit/Open

P0642



Sensor Reference Voltage "A" Circuit Low

P0643



Sensor Reference Voltage "A" Circuit High

P0651



Sensor Reference Voltage "B" Circuit/Open

P0652



Sensor Reference Voltage "B" Circuit Low

P0653



Sensor Reference Voltage "B" Circuit High

P0657



Actuator Supply Voltage "A" Circuit/Open

P0658



Actuator Supply Voltage "A" Circuit Low

P0659



Actuator Supply Voltage "A" Circuit High

P0670



Glow Plug Control Module Control Circuit/Open

P0671



Cylinder 1 Glow Plug Circuit/Open

P0672



Cylinder 2 Glow Plug Circuit/Open

P0673



Cylinder 3 Glow Plug Circuit/Open

P0674



Cylinder 4 Glow Plug Circuit/Open

P0675



Cylinder 5 Glow Plug Circuit/Open

P0676



Cylinder 6 Glow Plug Circuit/Open

P0677



Cylinder 7 Glow Plug Circuit/Open

P0678



Cylinder 8 Glow Plug Circuit/Open

P0679



Cylinder 9 Glow Plug Circuit/Open

P0680



Cylinder 10 Glow Plug Circuit/Open

P0684



Glow Plug Control Module to PCM Communication Circuit
Range/Performance



P0685



ECM/PCM Power Relay Control Circuit/Open

P0686



ECM/PCM Power Relay Control Circuit Low

P0687



ECM/PCM Power Relay Control Circuit High

P0688



ECM/PCM Power Relay Sense Circuit/Open

P0691



Fan 1 Control Circuit Low

P0692



Fan 1 Control Circuit High

P0693



Fan 2 Control Circuit Low

P0694



Fan 2 Control Circuit High

P0697



Sensor Reference Voltage "C" Circuit/Open

P0698



Sensor Reference Voltage "C" Circuit Low

P0699



Sensor Reference Voltage "C" Circuit High

P0700



Transmission Control System (MIL Request)

P0701



Transmission Control System Range/Performance

P0702



Transmission Control System Electrical

P0704



Clutch Switch Input Circuit

P0705



Transmission Range Sensor "A" Circuit (PRNDL Input)

P0706



Transmission Range Sensor "A" Circuit Range/Performance



P0710



Transmission Fluid Temperature Sensor "A" Circuit

P0711



Transmission Fluid Temperature Sensor "A" Circuit
Range/Performance



P0712



Transmission Fluid Temperature Sensor "A" Circuit Low

P0713



Transmission Fluid Temperature Sensor "A" Circuit High

Page 8 of 24

Volkswagen Engine and Transmission Fault Codes

12/3/2008

file://Z:\DOCS to be posted to Erwin\Volkswagen Engine and Transmission Fault Codes.h...

P0714



Transmission Fluid Temperature Sensor "A" Circuit Intermittent



P0715



Input/Turbine Speed Sensor "A" Circuit

P0716



Input/Turbine Speed Sensor "A" Circuit Range/Performance



P0717



Input/Turbine Speed Sensor "A" Circuit No Signal

P0720



Generator Control Circuit

P0721



Output Speed Sensor Circuit Range/Performance

P0722



Output Speed Sensor Circuit No Signal

P0725



Engine Speed Input Circuit

P0726



Engine Speed Input Circuit Range/Performance

P0727



Engine Speed Input Circuit No Signal

P0729



Gear 6 Incorrect Ratio

P0730



Incorrect Gear Ratio



P0731



Gear 1 Incorrect Ratio

P0732



Gear 2 Incorrect Ratio

P0733



Gear 3 Incorrect Ratio

P0734



Gear 4 Incorrect Ratio

P0735



Gear 5 Incorrect Ratio

P0736



Reverse Incorrect Ratio

P0740



Torque Converter Clutch Circuit/Open

P0741



Torque Converter Clutch Circuit Performance/Stuck Off

P0743



Torque Converter Clutch Circuit Electrical

P0746



Pressure Control Solenoid "A" Performance/Stuck Off

P0747



Pressure Control Solenoid "A" Stuck On

P0748



Pressure Control Solenoid "A" Electrical

P0749



Pressure Control Solenoid "A" Intermittent

P0751



Shift Solenoid "A" Performance/Stuck Off

P0752



Shift Solenoid "A" Stuck On

P0753



Shift Solenoid "A" Electrical

P0756



Shift Solenoid "B" Performance/Stuck Off

P0757



Shift Solenoid "B" Stuck On

P0758



Shift Solenoid "B" Electrical

P0761



Shift Solenoid "C" Performance/Stuck Off

P0762



Shift Solenoid "C" Stuck On

P0763



Shift Solenoid "C" Electrical

P0766



Shift Solenoid "D" Performance/Stuck Off

P0768



Shift Solenoid "D" Electrical

P0771



Shift Solenoid "E" Performance/Stuck Off

P0773



Shift Solenoid "E" Electrical

P0776



Pressure Control Solenoid "B" Performance/Stuck Off

P0777



Pressure Control Solenoid "B" Stuck On

P0778



Pressure Control Solenoid "B" Electrical

P0779



Pressure Control Solenoid "B" Intermittent

P0780



Shift Error



P0781



1-2 Shift



P0782



2-3 Shift

Page 9 of 24

Volkswagen Engine and Transmission Fault Codes

12/3/2008

file://Z:\DOCS to be posted to Erwin\Volkswagen Engine and Transmission Fault Codes.h...
